Accuracy Grade Current Transformer
ITEM |
CURRENT RATIO |
RATED WATTHOUR METER |
PHASE SHIFT |
RATIO ERROR(%) |
Hs-1W, Hs-1V, Hs-1H |
1,300 : 1 |
20A |
Max. 30¡Ç |
Max. 0.5% |
Hs-2W, Hs-2V |
1,000 : 1 |
30A |
Max. 20¡Ç |
Max. 0.5% |
H-1W, H-1H, H-1V |
2,500 : 1 |
40A |
Max. 12¡Ç |
Max. 0.2% |
H-2W, H-2H, H-2V |
2,500 : 1 |
60A |
Max. 12¡Ç |
Max. 0.2% |
H-3W, H-3V |
2,500 : 1 |
120A |
Max. 12¡Ç |
Max. 0.2% |
H-4W, H-4V |
2,500 : 1 |
200A |
Max. 12¡Ç |
Max. 0.2% |
H-1836W, H-1836V |
2,500 : 1 |
200A |
Max. 12¡Ç |
Max. 0.2% |
H-5W |
2,500 : 1 |
200A |
Max. 12¡Ç |
Max. 0.2% |
|
 |
| 1. Output(E2) : Measured after demagnetization. |
 |
| 2. GRAPH OF OUTPUT. |
Model |
¨ªA(Min.) |
B(Max.) |
C(Max.) |
D(Max.) |
FIG. |
5.8 |
17.3 |
8.1 |
19.3 |
2 |
|
6.3 |
19.8 |
9.5 |
20.3 |
1 |
|
6.5 |
23.8 |
11.8 |
25.4 |
1 |
|
8.7 |
25.3 |
16.8 |
27.4 |
1 |
|
11.9 |
30.0 |
17.7 |
30.1 |
1 |
|
12.7 |
37.6 |
14.1 |
39.1 |
1 |
|
17.2 |
36.3 |
17.6 |
35.8 |
1 |
|
21.9 |
48.4 |
17.1 |
51.3 |
2 |
Model |
¨ªA(Min.) |
B(Max.) |
C(Max.) |
D(Max.) |
E |
F |
G(¡¾0.5) |
H |
FIG |
5.8 |
17.3 |
8.3 |
19.3 |
10.0 |
3.0¡¾0.5 |
1 |
|||
5.9 |
17.3 |
8.0 |
18.2 |
10.0 |
7.5¡¾0.2 |
3.0¡¾0.5 |
2 |
||
6.3 |
19.8 |
9.5 |
20.3 |
11.0 |
3.0 |
1 |
|||
6.3 |
19.8 |
9.5 |
20.3 |
11.0 |
3.0 |
2 |
|||
6.8 |
23.6 |
11.7 |
25.3 |
15.0 |
11.0 |
4.0 |
2 |
||
8.7 |
25.5 |
16.8 |
27.5 |
15.0 |
2 |
||||
6.5 |
23.8 |
11.7 |
25.5 |
15.0 |
3.0 |
1 |
|||
6.5 |
23.8 |
11.7 |
25.5 |
15.0 |
19.0 |
3.0 |
10.5 |
3 |
|
8.7 |
25.5 |
16.8 |
27.5 |
15.0 |
19.0 |
3.0 |
15.5 |
3 |
|
11.9 |
31.0 |
18.0 |
31.7 |
22.8 |
26.5 |
3.0 |
16.7 |
3 |
|
12.7 |
37.5 |
13.7 |
38.9 |
25.0 |
33.0 |
3.0 |
13.0 |
3 |
|
17.1 |
36.3 |
17.8 |
35.7 |
25.5 |
33.0 |
3.0 |
16.5 |
3 |
- Customers' own electrical requirements also can be satisfied by utilizing our standard dimensions.
- Both horizontal and vertical PCB mounting types are available.
